DeatschWerks DW420 420lph Universal Fuel Pump - 9-421-1000

DeatschWerks DW420 420lph Universal Fuel Pump - 9-421-1000

The DW420 is our new flagship standard fitment in-tank pump. The DW420 flows 420lph at 40psi and is a popular choice for ethanol applications or wherever the highest flowing standard fitment in-tank pump is needed. Quiet operation and pulse width modulation compatibility are delivered via the turbine impeller and computer balanced armature. Ethanol compatibility is built in via the carbon commutators and a fully encapsulated armature. All DW fuel pumps are backed by a 3-yr no fault warranty.

Specifications:

• Weight - 362g
• External Materials - Electroplated Steel
• Inlet Fitting - 7.7mm ID, 11mm OD
• Outlet Fitting - 5/16" Hose Clamp
• PRV Activation - 110psi
• Impeller Design - Single Scroll Composite Turbine
• Connector Terminal - Spade Pos/Neg
• Min Voltage Input - 6 Volts
• Max Input Voltage - 18 Volts
• Current Draw @ 40psi - 15.9 amps (13.5v)
